    Underground Water Well Diamond 200m Core Drill Rig Machine

    Ask Lasest Price
    Brand Name : ShiTan
    Model Number : GK200
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, T/T, Western Union
    Supply Ability : 2000set/year
    Delivery Time : Within 7-12 days
    • Product Details
    • Company Profile

    Underground Water Well Diamond 200m Core Drill Rig Machine

    Water Well Machine GK-200 Diamond Core Drilling Rig

    GK-200 Product Description

    Our Underground Core Drilling Equipment Used Water Well Drilling Machine for Sale, is aportable light weight drilling rig. This product is widely used for geological general investigation andexploration of railway, road, bridge, dam and tall building base, geological core drilling, small grouting holes, blasting holes, civil wells and earth central air conditioning wells,etc.

    GK-200 Drill Rig Specification

    Drill rig specification
    Drilling depth200m
    Drilling Diameter91mm,110mm,130mm,150mm,300mm
    Drilling rod diameter50mm
    Drilling Angle90°-75°
    Dimensions(L×W×H)1750×850×1300 (mm)
    Weight880kg/set
    Swivel Head
    Spindle Speed115, 230, 505, 790, 1010 r/min
    Spindle stroke450mm
    Spindle Dia.Φ59mmx53mmx4350mm Kelly rod
    Upward displacement speed of drilling vertical spindle0.05m/s
    Downward displacement speed of drilling vertical spindle0.067m/s
    Spindle pull-down max15KN
    Spindle lifting capacity max25KN
    Vertical maximum output torque1.5KN.m
    Hoist
    Max. Lifting capacity(single rope)20KN.m
    Lifting rotating speed20; 40; 90; 168r/min
    Hoisting drum linear velocity (two levels)0.17; 0.35; 0.73; 1.5m/s
    Drum Diameter140mm
    Wire rope diameter9.3mm
    Wire rope capability40m
    Gear Pump
    ModelYBC-12/125
    Rated pressure12.5Mpa
    Displacement20ml/r
    Rated Speed2000r/min
    Mud Pump
    TypeBW-160
    Displacement160 L/min
    Working pressure1.3 Mpa
    Stroke85mm
    Drive shaft speed951 r/min
    Drive power5.88KW
    Diameter of inlet pipe45mm
    Diameter of outlet pipe38mm


    GK-200 Main Features:

    1) Compact structure, concentrated handle,small footprint, light weight, strong decomposition, and easy to move.
    2) Feed by hydraulic cylinder, the drilling efficiency is higher and it can save labor.
    3) The machine is equipped with our high technology taper clutch, it features strong torque transmission, easy operation and free maintenance.
    4) Vertical spindle are fixed by four groups of bearings to ensure that the rotatory machine has enough rigid for gravel layer and other complex geological conditions.

    GK-200 Precautions for courtyard drilling

    1. Consider whether the well depth is reasonable
    We should first investigate whether there are cables, sewers and other facilities under the ground, and avoid unnecessary damage.
    2. Convenience, health and other issues should be considered.
    After drilling the well, find some charcoal and throw it into the well with a bag and press it at the bottom of the well to absorb foreign toxins. After having water, you can put a few small fish down, which is a good way to test the safety of water quality.
    3. The well should not be too deep. It should be above the ground and should be blocked with bricks and stones. It is better to have a cover, so as to prevent dirt from falling in, make people feel safer and avoid unnecessary dangers.

    Underground Water Well Diamond 200m Core Drill Rig MachineUnderground Water Well Diamond 200m Core Drill Rig MachineUnderground Water Well Diamond 200m Core Drill Rig MachineUnderground Water Well Diamond 200m Core Drill Rig MachineUnderground Water Well Diamond 200m Core Drill Rig MachineUnderground Water Well Diamond 200m Core Drill Rig Machine
