    200m Portable Water Well Drilling Rigs Crawler Movement 220V/380V

    Ask Lasest Price
    Brand Name : JINZHOU SHITAN
    Model Number : ST-200
    Certification : ISO
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 2000 sets per year
    Delivery Time : 7-10 days
    • Product Details
    • Company Profile

    200m Portable Water Well Drilling Rigs Crawler Movement 220V/380V

    Cheap 200m Water Well Drilling Rig Crawler Movement Available for End Users


    Features of ST-200 Water Well Drilling Rig


    a. Keeping bracket is installed on the hosit to form a double wheel support structure, able to withstand strong blow


    b. Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rigidity to overcome gravel layer and other complex geological conditions.


    c. the machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.


    d. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.


    Main Parameter of ST-200:


    Drilling depth230m
    Maximum borehole caliber300mm
    Minimum borehole caliber75mm
    Diameter of Drill pipe42/50/60mm
    Drilling angle90°~75°
    Weight(Not include power)1150kg
    Unity machine dimension2750*950*1770mm
    2.Vertical Spindle
    Spindle rotating speed64/128/287/557r/min
    Spindle stroke450mm
    3.Hoist
    Max. single line lifting capacity2400kg
    Reel lifting speed1.64m/s
    Steel wire rope diameter13mm
    Steel wire rope capacity35m
    Hug floodgate diameter245mm
    Hug floodgate belt width70mm
    Movable distance400mm
    4. Mud pump
    TypeGS-200
    TypeHorizontal Single Cylinder with double function
    Max. DischargeDiesel engine 170L/min
    Electrical Motor 140L/min
    Max. Pressure3MPa
    Work Pressure1.5MPa
    5. Power
    Diesel engine22HP
    Electric Motor15KW
    6. Drilling tower
    TypeIntegrated on drilling rig
    Control systemHydraulic
    7. Trailer chassis
    Type4 wheels
